Video Robotics

Key Features

• Engineered and manufactured in USA
• Unique motor coupling design
• US Patent 7,473,041
• LANC remote control interface
• Best price in its class
• IP, 10/100 Base-T Ethernet
• Durable and rigid design
• RS485 or RS232 serial control
• Lightweight, anodized aluminum
• USB port
• High performance Maxon motors
• IrDA serial communication port

Specifications

• 8 open collector outputs for user defined control
• 8 general purpose inputs for user defined status indication
• 4-channel analog IN for user defined or analog PID control
• 4-channel analog OUT for user defined or analog PID control
• 4 limit switches inputs for user defined end of travel
• 2 high current relays for user defined control
• Pan travel: adjustable +/-165° w/endstops
• Tilt travel: adjustable +/-165° w/endstops
• Position accuracy: 0.1°
• Payload: 25lbs
• Weight: 5lbs
• Power input: 24VDC/1.6A

System Accessory Options

• Tablet or PC
• Video Robotics user interface software (Windows based)
• USB Video Management (VM) Controller
• Network switches
• Dual-band wireless routers
• Directional Yagi antennas
• Camera power
• Zoom, focus, iris lens control
• Project-specific custom system modifications
• Rigid no-vibration wall and ceiling brackets
